$999.00
2 in stock
2 in stock
Usually ready in 4 hours
Here are the features & specifications of the Atomos Ninja TX 5.2″ Camera to Cloud Monitor/Recorder available to order online at iCon Cameras
Dual 12G-SDI and HDMI 2.0 inputs/outputs with loop-through, for compatibility with professional video rigs and long cabling workflows.
Records up to 8K/30 RAW (via HDMI input) and high frame-rates at lower resolutions (4K60, HD up to 120 fps) depending on the camera signal.
Supports pro codecs out of the box (Apple ProRes / ProRes RAW, Avid DNx, H.264 / H.265) — no extra unlocks needed.
New AtomOS Linux-based operating system; redesigned for more efficient cooling, quieter operation, better thermal performance.
5.2-inch IPS touchscreen display with high brightness (≈ 1500 nits), full Rec. 709 gamut + HDR tools, LUT support, calibration support.
Built-in “Camera-to-Cloud” (C2C) workflows: wireless uploading to platforms (Atomosphere, Dropbox, Frame.io) plus NDI/HX streaming.
AirGlu timecode sync over RF or Bluetooth: helps sync multiple devices (monitors, audio recorders, cameras) accurately.
Locking cable adapters / rugged build, cable protection / bracketed ports to make it more field-friendly.
| Category | Specification / Feature |
|---|---|
| Display | 5.2-inch (≈ 13.2 cm), IPS touchscreen; native resolution 1920 × 1080; brightness ≈ 1500 nits; aspect ratio 16:9; Rec. 709, HDR tools, LUT support, calibration. |
| Video Input / Output | • HDMI 2.0 input & output (supports up to 8K/30 fps via HDMI; 4K60; 1080p120) • 12G-SDI input & output with loop-through • Cross-conversion HDMI ↔ SDI supported. |
| Recording Media / Storage | CFexpress Type B slot; also supports recording to external USB-C storage. |
| Codec Support | Apple ProRes / ProRes RAW; Avid DNx; H.264 / H.265; all major codecs pre-activated. |
| Wireless & Network Features | Built-in Wi-Fi 6E; Bluetooth; NDI 6 / HX3 TX/RX streaming; Camera-to-Cloud upload to Atomosphere / Frame.io / Dropbox. |
| Timecode & Sync | AirGlu timecode sync (RF + Bluetooth) for multicam and multi-device workflows. |
| Power / Power Input | • Input voltage 6.2-16.8 V DC • USB-C PD input up to ~45W • Also NP-F battery plate / L-Series mount / battery plate included. |
| Size & Weight | Dimensions: 151 × 92 × 36 mm (≈ 5.94 × 3.62 × 1.42 in) Weight: 400 g (≈ 14.11 oz, ~0.88 lb) (body only; without battery/plate as specified) |
| Power Consumption | Up to ~30 W under load (e.g. during 8K recording or heavy processing) |
| Environmental / Build | Ambient operating temperature ≤ 40 °C; body construction: aluminium + ABS plastic; active cooling (fan + heatsink) for thermal management; locking cables / rugged ports. |
| Monitoring Tools | EL Zone false color; focus peaking; waveform; RGB parade; vectorscope; frame guides; safe areas; anamorphic de-squeeze; LUT upload; HDR/HLG / PQ support. |
Z 5 is powered by Nikon’s fast, comprehensive EXPEED 6 image processing system. It’s the secret behind the camera’s sensational photo and video quality, autofocus performance, low-light capabilities, distortion control, image clarity, color reproduction and more.
Sharpness starts with stability, and Z 5 has one of the best in-camera image stabilization systems available. NIKKOR Z lenses activate 5-axis VR image stabilization—up to five stops* of stabilization in up to five directions
Freeze time with shutter speeds as fast as 1/8000 of a second—fast enough to capture moments invisible to the naked eye. When shooting with wide aperture settings for shallow depth-of-field and blurred backgrounds, that speed can also be used to control your shot’s brightness.
Z 5 is powered by Nikon’s fast, comprehensive EXPEED 6 image processing system. It’s the secret behind the camera’s sensational photo and video quality, autofocus performance, low-light capabilities, distortion control, image clarity, color reproduction and more.
Sharpness starts with stability, and Z 5 has one of the best in-camera image stabilization systems available. NIKKOR Z lenses activate 5-axis VR image stabilization—up to five stops* of stabilization in up to five directions
Freeze time with shutter speeds as fast as 1/8000 of a second—fast enough to capture moments invisible to the naked eye. When shooting with wide aperture settings for shallow depth-of-field and blurred backgrounds, that speed can also be used to control your shot’s brightness.
